850nm OSFP Transceiver Module 400G SR4.2 Dual Rate 100m With MPO-12
Product Details:
| Place of Origin: | China |
| Brand Name: | ColorOptic |
| Certification: | ROHS, CE |
| Model Number: | CO-OS4H85SR4.2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Seal trays and cartons |
| Delivery Time: | 8 DAYS |
| Payment Terms: | TT, LC, Western Union |
| Supply Ability: | 1000 pieces/month |
|
Detail Information |
|||
| Dimension: | 70mm*42mm*18mm | Wavelength: | 850nm |
|---|---|---|---|
| Transmission Distance: | 150m | Form Factor: | OSFP Module |
| Relative Humidity: | 5% To 95% | Storage Temperature: | -40℃ To 85℃ |
| Fiber Type: | Multi-mode | Operating Temperature: | 0℃ To 70℃ |
| Highlight: | 850nm OSFP Transceiver,OSFP Transceiver 400G |
||
Product Description
OSFP Transceiver 400G SR4.2 Dual Rate 100m With MPO-12 For Industrial-Grade Connectivity Module
Product Description:
The 400G OSFP SR4.2 is an optical module designed for dual rate high-speed data transmission. It supports a data rate of 400Gbps and utilizes the OSFP form factor. The SR4 designation indicates that it is a short-reach module, typically used for connections within a data center or between closely located network devices. This module is capable of transmitting data over multimode fiber optic cables and is commonly used in high-performance computing, cloud computing, and other data-intensive applications.
Features:
- OSFP MSA compliant
- 8x53.125Gb/s electrical interface (400GAUI-8)
- Up to 150m OM5 MMF transmission
- Operating case temperature: 0 to 75oC
- Single 3.3V power supply
- Maximum power consumption 10W
- MPO-12 optical connector
- RoHS-6 compliant
Technical Parameters:
| Parameter | Symbol | Min | Typical | Max | Units | No |
| Operating Case Temperature | TOP | 0 | 70 | degC | ||
| Link Distance with OM3 | D | 0.5 | 100 | m | ||
| Power Consumption | 10 | W | ||||
| Center Wavelength | λ1 | 844 | 863 | nm | ||
| Center Wavelength | λ2 | 900 | 918 | nm | ||
| Average Launch Power, each Lane |
PAVG | -6.5 | 4 | dBm | ||
| Outer Optical Modulation Amplitude (OMAouter), each Lane |
POMA | -4.5 | 3 | dBm | ||
| Average Receive Power, each Lane |
-8.5 | 4 | dBm | |||
| Receiver Sensitivity (OMAouter), each Lane |
SEN | Max (- 6.6, SECQ – 8) | dBm |
Applications:
Customization:
ColorOptic's CO-OS4H85SR4.2 OSFP Module is a high-performance, high-density optical transceiver designed for applications such as Infiniband and Ethernet. It features a connector of MPO-12/16 and a transmission distance of 150m. The module is compliant with OSFPxmsa.org and NDR networking standards, making it compatible with IEEE802.3ae. It can reach a distance of up to 150m.
